What is the minimum hole size that can be opened by etching, and what are the spacing and precision of the holes?

Answer: The minimum opening size for Yoda Fa''s etching is related to the material thickness. Currently, the smallest opening that can be etched is 0.08mm, but the material thickness must be between 0.03-0.05mm. For example, with stainless steel at 0.1mm thickness, a hole spacing of 0.1mm can be achieved. The maximum depth accuracy reaches +/-0.0075mm. Correspondingly: the thicker the material, the larger the opening needs to be, and the wider the hole spacing. Generally, it can be approximated as: the minimum hole size for a given material thickness is 1.5 times the thickness value. Hole tolerance can be roughly controlled at 10% of the material thickness.

What is the material thickness for Yaoda''s etching processing?

Answer: Currently, the main material thickness for etching processing is 0.02-1.5mm, and thicknesses above 1.5mm can also be produced, but selectively, with precision control requirements being the main focus. Among them, Yaoda has the ability to carry out various thickness matching processing through machining and etching, which enables better and complete production of the entire set of products.

What materials can Yaoda Fa etch and corrode?

Answer: Currently, Yaoda Fa mainly uses metal materials such as stainless steel (SUS304, SUS301, SUS430, SUS631, CROFER22), copper C5191, C1020, C7710, and copper alloys for etching and corrosion. Rare metals are also processed, such as molybdenum and aluminum alloy materials.

What is the minimum size of holes that can be etched, and what is the spacing and precision of the holes?

Answer: What is the minimum size of holes that can be etched, and what is the spacing and accuracy of the holes? The minimum opening is related to the material thickness. The minimum opening that can be made at present is 0.1mm, but the thickness of the material must be 0.03-0.05mm. Taking 0.1mm thick stainless steel as an example, a hole spacing of 0.1mm can be made. The maximum depth accuracy reaches+/-0.0075mm. Correspondingly, the thicker the material, the larger the opening and the wider the spacing between the holes. The general ratio of opening to thickness is: ∮=1.5*T

Question: What is the processing technology for tearing off gaskets?

Answer: YDF is a manufacturer of processed layer tear off gaskets, specializing in customized layer tear off gaskets. Customers are required to provide relevant processing drawings or dimensional specifications. The commonly used materials are stainless steel, brass, and aluminum alloy. The commonly used single-layer thicknesses are 0.05 and 0.1. The total thickness can be adjusted according to customization. The more quantity, the cheaper the unit price.

Which is good for metal etching processing in Shenzhen?

Answer: Metal etching processing is a relatively emerging industry in the Shenzhen area. After years of accumulation and development, the industry benchmark effect has become increasingly strong. The metal etching processing mentioned is highly praised for its excellent quality and service provided by Shenzhen Yaoda Fa Precision Etching Processing. We are an early established enterprise in the Shenzhen area specializing in providing metal etching processing.

Which is a good stainless steel etching processing manufacturer?

Answer: Shenzhen Yaodafa is a professional enterprise dedicated to high-end etching processing. The team, quality, and processing are all subject to process control. If you want to ask which stainless steel etching processing manufacturer is good, choose the professional Shenzhen Yaodafa Precision.

What factors make up the control accuracy of metal etching?

Answer: The control accuracy of metal etching is composed of complex factors, usually including material material, material thickness, photoresist quality, exposure energy, development and etching control. Interlocking and requiring a systematic control. Yaodafa Precision is a professional etching process with system control and high precision. Liu Sheng 13534257051 Email ly@sz-ydf.com
